Metal Ball Screw nut KGX150 Heavy Load Precision Workbench Large Load Slide Module Double Linear Rail Ball Screw Linear Motion Rail Actuator(700mm Stroke)

1. High precision, low running noise, stable and durable, easy installation and maintenance. Rebound resistant, can be used vertically.2. Low friction, long service life; Excellent static and dynamic stiffness; High positioning, more accurate positioning; No stick-slip effect, less heat, reduce the required drive power.3. Can be used for CNC, machine tool DIY, student projects, family projects, simple experiments and other creative, manufacturing and industrial needs.Specifications:Model: SK-KGX150Guide rail width or diameter: 150mmStroke: 100-1000MMHorizontal load: 200KGVertical load: 150KGRepeat positioning accuracy: 0.03mmMaximum speed: 300mm/sScrew accuracy: C7Screw model: SFU2005 (Hint: SFU2005 means: screw diameter 20mm, pitch 5mm, screw rotation once, panel moves 5mm)Description:Thickened aluminum profile, equipped with 20mm double guide rails and four sliders, horizontal load-bearing 200KG, vertical load-bearing 150KG, better overall processing stability and load-bearing capacity, the slider module is equipped with 20mm double linear guide rails and four sliders to ensure stable operation, locking nut double bearing design, double bearing locking nut design increases load and reciprocating accuracy.Packing list:Actuator * 1

• 1. Anti-slip effect, less heat, less driving force required, high static and dynamic stiffness.
• 2. Small friction, long service life, low running noise, but no stick-slip effect, less heat, reduce the drive power.
• 3. Small friction loss, high transmission efficiency.
• 1. Good shock absorption, low noise, long life, etc.
• 2. Improve product precision and release module performance
• 3. The module has a simple structure, solid materials, small size, high precision, easy maintenance, and strong reliability
• 4. Stable structure, smooth operation, and long service life
